PSS SF 620 Speed Flaker

Send enquiry
PSS SF 620 Speed Flaker, capacity 6 t/h
  • PSS SF are designed for the food industry operations for fast cutting of whole frozen meat blocks and other various foodstuff with the temperature down to -25 °C.
  • PSS SF ensure gentle and clean product cutting to small, medium and large flakes.
  • PSS SF cutting thicknesses are in the variant A 3/6/9 mm and in the variant B 14/17/20 mm.
  • The frozen meat blocks and other foodstuff are put on the tilting loading table of PSS SF and they are automatically pushed towards the cutting drum, while the thruster ensures the optimal block position for clean and quality product cutting.
  • PSS SF achieve a high performance also by the cutting drum design, which processes the blocks of dimensions 600x400x200 mm.
  • There are 7 knifes placed on the cutting drum that can be standardly adjustable to 3 cutting thicknesses.
Main characteristics
Parameter PSS-SF-620
Power, kW 11,0
Weight, kg 960
Dimensions (LхWхH), mm
2378x1168x1470
Capacity (depending on the meat block size), kg / h.
А) grinding to 3/6 / 9 / mm
B) by crushing to 14/17/20 / mm


6000
6000
Crushing cavity dimensions, mm 620x600x270
E. current 3/PE/N, 50Hz, 230/400V, TN-C-S
Power supply
230/24 V AC
